Details
Our bikes have always been about amplifying fun, so our goal for the Heckler MX was to make something light and agile that can help you on-site blind terrain.
A mixed-wheel bike gives the confidence of a 29-inch wheel up front for traction and roll-over when you're caught off guard by technical features. The 27.5-inch rear wheel allowed us to keep the moderate chainstay length of the Heckler (445mm), which provides a snappy and easy-to-handle bike on tight, demanding trails. We did this without compromising on the standard Heckler's geometry, so the bike's character is still very light and accurate.
The Heckler is about expanding your own trail map—accessing previously unreachable trails, unlocking less-used trails and doing so independently. Whether tackling rides that are guarded by monstrous climbs, or cramming more into less time, it's about rarer rides becoming the norm for you. The interchangeable 500wh battery keeps the weight down compared to bikes with larger batteries but it's fast and easy to put in a fresh battery for even bigger, longer days.
The new Shimano EP8 motor is lighter than E8000 drive unit (380g), has more power (85Nm versus 70Nm), smaller volume (-10%) for greater ground clearance, less drag (50%), more heat resistant, and is tuned to give more power in Trail mode. All this means it's even more capable of tackling longer, tougher rides. We use the full Shimano STEPS battery and motor system again because it means assured reliability and global aftermarket service.
Specs
Frame | Carbon CC 27.5 140mm Travel VPP |
---|---|
Fork | RockShox Pike Select+, 140mm, 29" |
Rear Shock | Fox Float Performance Elite DPS |
Rims |
Front: RaceFace AR Offset 30 29" Rear: RaceFace AR Offset 30 27.5" |
Hubs |
Front: DT Swiss 370, 15x110, Torque Cap, 32h Rear: DT Swiss 370, 12x148, XD, 32h |
Spokes | Sapim Race |
Tires |
Front: Maxxis Minion DHF 29 x 2.5", 3C, MaxxGrip, EXO, TR Rear: Maxxis Minion DHR II 27.5 x 2.4", 3C, EXO+ |
Crankset | Shimano EM600 Crank Arms, 165mm |
Shifters | SRAM GX Eagle Single Click, 12spd |
Rear Derailleur | SRAM GX Eagle, 12spd |
Cassette/Freewheel | SRAM XG1275 Eagle, 12spd, 10-52t |
Chain | SRAM GX Eagle, 12spd |
Brakes | SRAM Code R |
Rotors | Avid Centerline 200mm |
Handlebars | Santa Cruz Bicycles Carbon Di2 Bar |
Tape/Grips | Santa Cruz Palmdale |
Stem | Burgtec Enduro MK3 |
Headset | Cane Creek 40 IS Integrated |
Seatpost | SDG Tellis |
Saddle | WTB Silverado Pro |
Pedals | Sold separately |
Accessories & Extras | E13 E-Spec+ AL chainguide |
Motor | Shimano Drive Unit DU-EP800 |
Battery | Shimano 504Wh Integrated |
Controller/Display | Shimano Display Unit SC-E7000 |
* Subject to change without notice.
Videos
Part Numbers
Option | UPC | MPN |
---|---|---|
Gloss Carbon / Medium | 192219191140 | 58-21216-107-3-716-403001-01 |
Gloss Carbon / Large | 192219191072 | 58-21216-107-4-716-403001-01 |
Gloss Carbon / X-Large | 192219176802 | 58-21216-107-5-716-403001-01 |
Gloss Carbon / XX-Large | 192219150871 | 58-21216-107-6-716-403001-01 |
Fog / Medium | 192219176475 | 58-21216-107-3-717-403001-01 |
Fog / Large | 192219183367 | 58-21216-107-4-717-403001-01 |
Fog / X-Large | 192219150765 | 58-21216-107-5-717-403001-01 |
Fog / XX-Large | 192219150987 | 58-21216-107-6-717-403001-01 |
